Elas Ltd. has been the Hungarian representative of the Speedline Group since its establishment. MPM, a member of this group, offers a wide range of stencil printers to meet the most demanding requirements, which, thanks to their high precision and short cycle times, greatly increase the production yields of electronics manufacturing and assembly plants. Over the past decade, we have installed more than 100 MPM stencil printers in Hungary.

MPM's equipment can be used to apply solder pastes, adhesives and other materials used in printed wiring boards. MPM stencil printers are long-life, highly reliable, precision (up to 12.5 micron (6 sigma) panel-to-stencil splice accuracy), flexible, and allow for rapid product changeovers. The range includes smaller, stand-alone, semi-automatic and fully line-ready equipment. Drawing on previous experience and expertise, MPM has developed the industry's first 2D and 3D print inspection systems, vacuum stencil cleaning, Automatic Pin Placement, look-up/look-down camera systems, closed-loop print pressure control. Many of today's widely used solutions are also related to them, such as enclosed-pump print head technology, texture-based bridge inspection, parallel processing of stencils. With Speedline MPM systems, we offer our customers the most economical solution in stencil printing equipment. With the MPM range of Accela (specifically for high productivity production lines) and Momentum (for medium and low capacity production), we can offer our customers a solution to meet their specific needs.



Main features of the Accela series:



  • MPM's patented Parallel Processing stencil printing operations
  • +-12.5micron accuracy @ 6 sigma, with Cpk >= 2.0
  • Less than 5.5s cycle time
  • EdgelocTM panel mounting
  • Digital up/down camera
  • Bottom stencilling
  • Print quality control (paste and short-circuit, stencil aperture paste residue control) configurable according to customer needs
  • Adjustable stencil grip size





Main features of the Momentum series (Momentum Dual Lane, MPM 125, Momentum Compact):



  • +-12.5micron accuracy @ 6 sigma, with Cpk >= 2.0
  • Up to 7s cycle time
  • Automatic support placement
  • EdgelocTM panel mounting
  • Digital up/down camera
  • Bottom stencilling
  • Print quality control (paste and short-circuit, stencil aperture paste residue control) configurable according to customer needs
  • Adjustable stencil grip size



The MPM website: http://www.speedlinetech.com/mpm/index.aspx



SMT - Surface Mount Technology is an electronic assembly process where components are directly mounted on the contact surfaces (pads) of a printed wiring board and then soldered or soldered to it.
