Process module

The integratable dispenser

By integrating Scheugenpflug's dispensing solutions into the Process Module, they can be easily integrated into individual new or existing automated production lines and cells. The integrated unit ensures unchanged accuracy of dosing volume and location thanks to Scheugenpflug dosing heads and shaft systems. To meet different needs, the module is available in both entry-level Basic and extended Premium configurations.

  • Easy to use and program
  • Precise 3- or 4-axis CNC system (20 micron setting accuracy - measured on X; Y axis)
  • Speed 160 or 500 mm/sec
  • Stepper or servo motor
  • DosP and DosGP can be fitted with dispensing heads
  • Can be connected with tube holders or Scheugenpflug with material preparators
  • Needle gauge unit - needle deflection compensation
  • Parking glass - needle asphyxiation prevention
  • Pot life calculation - mixing stem against drying
  • Built-in weight measurement - scheduled control of the dosage quantity
  • Work spaces of different sizes can be created
  • Product, palette, dispensing head and mixing stem heating
  • Product position or type sensor
  • Different intreface options available

Shaft speed: 160 or 500 mm/s

X, Y, Z axis accuracy: ± 0.02 mm


  • From 700 × 1000 mm
  • Up to 1400 × 1300 mm

Power supply: 3 x 400 V~, 50/60 Hz, CEE 16 A

  • Fire detection unit

    Laser positioning of the needle and correction of the robot's movement to ensure accurate feeding at all times

  • Product sensors

    Product position detection solutions

  • SCP210-s control unit

  • Balance

    Automatic weighing, to always achieve the exact amount dispensed


Process modules

Integrated dosing solution with axis system, dosing volume and position from one hand!

Professional automation solution

For gluing, sealing, filling or heat-conducting paste dispensing!
