The Pillarhouse Synchrodex Inline selective soldering system is fully modular, allowing a high degree of flexibility. Each module is a stand-alone unit, independently configurable and movable. You are free to choose between fluxer only, fluxer and preheater combined, preheater only and soldering modules. This allows flexibility to match the investment to the required yield, maximising the return on investment.

  • Inline modular design
  • Same design as Pillarhouse Handex, options
  • Conveyor system with automatic width adjustment and side clamping
  • Manage even frameless panels
  • Positioning with positioning points and Z altimeter sensor
  • Built-in extraction
  • Complete selective soldering lines Nutek conveyor tracks are available with up to palette rebates
  • Equipment dimensions: 1615 x 813 x 2024 mm (M x W x H)
  • Max. panel size: 457mm x 610mm
  • Nitrogen consumption: 10-30 litres/minute
  • Required Nitrogen purity: 99.995% or cleaner
  • Required Nitrogen pressure: 5 bar
  • Required air pressure: 5 bar
  • Air consumption: 10 litres/minute
  • Power supply: 230V, 50/60 Hz, up to 13 kVA (depending on the configuration of the equipment)
  • Ultrasonic flux application unit
  • Top infra preheating unit
  • Lower slide-in and slide-out infra preheater unit
  • Closed feedback preheating with pyrometer
  • Encoder feedback on X, Y and Z axes
  • Automatic solder roll dispenser with built-in recognition
  • Closed feedback preheating with pyrometer
  • Position point detection and correction system
  • Microphone nozzle

    1.5 mm micro nozzle for the most difficult solder points.

  • Modular design

    Custom production lines can be configured from fluxer, preheater and soldering units

  • Double bedroom

    Two hot tubes for different alloys or nozzle designs

  • Dual fluxer

    Ultrasonic and/or dropjet fluxer can be selected.


Pillarhouse Synchrodex

The Pillarhouse Synchrodex is a modular inline selective soldering system.
