MSD series

Members of the MSD drying cabinet range are Totech's most popular models thanks to their powerful U-5000 unit and modularity. The central cabinet can be expanded with extension units as required, doubling or even tripling its dry storage capacity. The cabinet is ideal for software-traceable storage of reels, trays, stick feeders or even semi-finished and finished products.

  • Reels, trays, stick feeders, finished and semi-finished products up to entire magazines can be stored
  • Totech patented drying unit U-5000 for setting relative humidity (RH) 0,5%
  • Expandability with additional MSD-1223 extension units
  • Sensor humidity and temperature measurement (±0.8 RH%)
  • Dynamic regeneration
  • Digital display
  • Light and sound signals
  • Economic consumption
  • Adjustable polck distribution
  • ESD design
  • Totech Monitor software for constant cabinet status monitoring and data collection up to simultaneous monitoring of multiple cabinets
  • MSL 2.0 full-featured parts tracking software
  • Optional heating up to 40C°
  • Optional nitrogen atmosphere

Capacity: 1200 L per module

External dimensions: 840 x 2040 x 900 mm (W x D x W x D)
Internal dimensions:

MSD1222 central unit: 830 x 1780 x 730 mm (W x D x W)

MSD 1223 extension unit: 830 x 1780 x 850 mm (W x D x W)
Weight: 130 kg per module

Shelf load capacity: 50 kg

  • Integrated MSL parts register system
  • MSD-1222-55-S

    MSD series with integrated MSL parts register

  • 5001 Dry-unit

    Dehumidification unit 0.2% to create relative humidity within 10 minutes.

  • Totech Monitor

    Complete cabinet tracking system for up to several Totech cabinets.

  • MSL parts inventory system

    Monitoring of humidity sensitive parts inside and outside the cabinet.

  • HSD display

    Intelligent user interface.


MSD's modular cabinet
