Mirtec MS-11 SPI

A quality cost-effective solution



A significant proportion of defects in the manufacture of electronic products are caused by the application of solder paste. Whether the defect is blurring, little, missing or excess paste, offset printing or any paste-related defect that could affect the quality of your product down the line, the Mirtec MS-11 SPI machine will find it. Its advanced imaging system, using Dual Moire technology, produces shadow-free information about the product to be processed, which is immediately evaluated by a powerful image processing unit running in the background. Its outstanding speed guarantees that there will never be a bottleneck on the production line.



The equipment is simple to build, requires no engineering skills to program, and is cost-effective.



With our supported closed-loop system, we have the possibility to transfer the results measured by Mirtec or their extracts to the Paste printer or SMT implantation machines, automatically maintaining high quality production.





GO TO THE MANUFACTURER'S WEBSITE

DOWNLOAD DATA SHEET

  • Details
  • Parameters
  • Options
  • High speed precision inline SPI equipment
  • Advanced dual shadowless MOIRÉ imaging
  • 4 - 15 MP camera
  • 10 microns/pixel resolution
  • Telecentric lenses
  • Patented CoaXPress technology - faster image processing time
  • 2 micron accuracy (Z axis)
  • Precision AC servo drive
  • Extremely easy programming and machine operation
  • Laser panel curvature compensation
  • Panel size: min. 50 mm x 50 mm - max 510 mm x 460 mm
  • Typical defects that can be tested: soldering waste or shortage, offset printing, short circuit, solder height, etc.
  • Manual or camera barcode reading
  • Remote SPC software
  • Dual lane design

  • Double Moire projection

    For a fully shadow-free 3D SPI test.

  • Up to 25 MP camera

    The highest resolution available on the market.

  • CoaxPress technology

    Enhanced data transmission technology

  • Wider field of view (FOV)

    15 MP camera with larger field of view, shorter cycle times.

  • Laser panel curvature analysis

Videos

Mirtec MS-11

Insightful video on how the Mirtec MS-11 SPI works
