Jade

Most popular offline soldering machine

This Pillarhouse offline selective soldering system is designed for small batch production units where flexibility is the most important factor. While the JADE Pro is equipped with one soldering bath, the Duplex version is equipped with two independent Z-axis moving baths. Duplex thus allows the different solder alloys required for different makes to be changed without expensive and long changeover times. The equipment can be fitted with a small soldering nozzle of 1.5 mm diameter, unique on the market, which allows even the most difficult soldering tasks to be carried out.

Thanks to its easy programmability and simple operation, it is the world's most popular offline soldering system.


  • Offline design
  • 1,5 - 25 mm soldering nozzles
  • Single (Jade Pro) or two independent z-axis hot tub (Duplex) designs
  • Automatic hot tub replacement (max 4 hot tubs!)
  • Visual teaching system based on panel image (Jpeg or Gerber)
  • Adjustable size PCB frame holder
  • Preheating control with an infrared thermometer
  • Dropjet or ultrasonic fluxer
  • Manual or automatic positioning point control
  • Measuring and adjusting the source wave height
  • Flux presence check (against clogging, running out)
  • Integrated nitrogen purity measurement
  • Lead or lead-free design
  • PillarPAD offline programming software

JADE MKII

  • Equipment dimensions: 1403 x 1000 x 1351 mm (M x W x H)
  • Max. panel size: 457mm x 508mm
  • Hot tub capacity: 8 kg
  • Nitrogen consumption: 35 litres/minute
  • Required Nitrogen purity: 99.995% or cleaner
  • Required Nitrogen pressure: 5 bar
  • Required air pressure: 5 bar
  • Mains supply: 208 - 250 V, 50/60 Hz, 6.5 kVA (with top-side preheater), 8kVA (with top-side preheater and bottom-side ring preheater)

JADE PRO

  • Equipment dimensions: 1230 x 1250 x 1495 mm (M x W x H)
  • Max. panel size: 457mm x 508mm
  • Hot tub capacity: 20 kg (standard) / 30 kg (large)
  • Nitrogen consumption: 40 litres/min (single hot tub design) / 80 litres/min (Duplex design)
  • Required Nitrogen purity: 99.995% or cleaner
  • Required Nitrogen pressure: 5 bar
  • Power supply: 230/400 V, 50/60 Hz, up to 9kVA (depending on configuration)





  • Rotary table design for fast product changeover even during the process
  • Dual dropjet and ultrasonic flux application unit
  • Top infra preheating unit
  • Bottom ring infra preheater unit
  • Bottom-side heated nitrogen injection preheating
  • Closed feedback preheating with pyrometer
  • Encoder feedback on X, Y and Z axes
  • Laser panel curvature compensation
  • N² flow measurement unit
  • Flux flow rate measuring unit
  • Automatic solder dispenser
  • Hot tub quick change trolley with independent preheating
  • Checking the speed of the booster pump
  • Nitrogen Generator - Pillargen
  • Microphone nozzle

    1.5 mm micro nozzle for the most difficult solder points.

  • Double bedroom

    Two hot tubes for different alloys or nozzle designs

  • Preheatable hot tub

    Quick-change hot tub station with offline heating.

  • Panel curvature test

    Correction of soldering according to the curvature of the product.

  • Ring theatre

    Fast and selective preheating option

  • DropJet fluxer

    Selective and precise flux application

  • Ultrasonic fluxer

    Spray flux application for larger areas

  • New pump unit

    Easy installation, longer life.


Videos

Pillarhouse JADE MK II

Flexible offline selective soldering equipment.

Pillarhouse JADE PRO Series

Off-line selective soldering system with up to two independent Z-axis soldering baths.
