GO semi-automatic printers

The motorised GO semi-automatic stencil printer family in a compact desktop size. Thanks to its adjustable print speed, knife width and separation and camera-assisted positioning, the machine is an excellent solution for small to medium volume precision printing. With the GoLED version, it is also possible to print on extra-large panels (1400×420 mm) such as LED panels.


  • Software control, touch screen and program writing facility
  • Adjustable print speed (20-150 mm/s)
  • Adjustable knife force: 40-120 N
  • Smallest printable part: 01005 (0402 metric) chip
  • Laser-guided camera system for stencil alignment
  • Alignment accuracy:X, Y, (theta): +/- 10mm (+/- 1.5°)
  • Pneumatic separation with precise adjustable speed (0.5-6 mm/s)
  • Multiple panel support types
  • Pneumatic stencil clamping
  • GoLED design for large panels (1200 x 1400 mm)
  • Panel size:
  • Min. 50 x 60 x 25 mm - max 620 x 550 mm
  • Panel thickness: 0,5 -4 mm
  • Maximum bottom hang 23,5 mm
  • Printable area:
  • GO29 600 x 540 or GoLED 1200 x 1400 mm
  • Stencil size:
  • Min. 300 x 300 x 25 mm - max 762 x 780 x 40 mm
  • GoLED 1500 x 600 x 40 mm
  • Magnetic table

    For flexible clamping.

  • Dual camera

  • stencil clamp

  • Touch screen interface


Videos

Go23 & Go29 printer

Camera-assisted matrix semi-automatic stencil printer family for flexible small and medium batch production.

GoLED printer

The machine is ideal for printing large panels (max. 1400x420 mm), such as LED panels.
