FluxClean T4

High capacity frame washer

Today, with selective soldering stations becoming more and more common, there is still a need to clean wave soldering equipment and with it wave soldering pallets. PBT's custom-developed machine protects pallets from damage and increases the lifetime of the pallets by using a high-capacity liquid flow process and efficient drying. The machine is also suitable for washing soldering machine components such as reflow oven condensers.


  • Fencing, liquid flow Spray under immersion washing chamber
  • High pressure Spray in air rinsing chamber
  • Fully automatic operation
  • Two pump cleaning sections
  • Odour-free sealed cleaning compartment
  • There are always 2 baskets in the washing cycle (the first in the cleaning phase, the second in the rinsing and drying phase)
  • Hot water rinse max 50°C
  • Drying temperature max. 110°C

- Equipment dimensions: 880 × 1680 × 1866 mm (W x H x D), 750 kg
- Effective basket size: 830 x 450 x 470 mm

Typical cycle times:

  • Cooking frame 10-15 minutes
  • Condensation trap 20-30 minutes
  • Washing trolley

    Baskets travelling on a trolley are automatically loaded into the machine.


Videos

FluxClean T solder frame cleaner

High-efficiency frame washer with automatic wash basket handling and spray under immersion technology.
