FA23 automatic offline printer

Designed for small and medium sized manufacturing companies, this flexible, fully automatic offline paste printing station is the perfect solution for today's printing requirements. It features an automatic positioning system with camera and a built-in stencil wiping solution.


  • All print parameters are programmable (knife force, print speed, print path length, separation speed and distance)
  • 3 levels of access (operator, supervisor, service)
  • Windows-based software user interface
  • Pneumatic-hydraulic separation system
  • Wide range for panel beams
  • Automatic panel positioning system with two colour cameras
  • Built-in stencil wiper
  • Saving print parameters
  • Quick programme setup
  • Cycle time 15 - 30 sec
  • Panel size: min. 50 x 60 mm - max 460x 410 mm
  • Panel thickness: 0,5 -4 mm
  • Maximum bottom overhang 63,5 mm
  • Printable area: 440 x 490 mm
  • Stencil size: min. 584 x 584 x 18 mm - max 584 x 680 x 40 mm
  • Delay 1-3 N/cm
  • Print speed: 10-99 mm/s
  • Separation speed: 0.1-3.5 mm/s
  • Print speed +/- 20 um in 3sigma
  • Camera-based positioning

    Double colour camera stencil matching can be set up on Windows based printer software.

  • Stencilling

    Manual dry erase function available

  • Magnetic table

    Flexible spike or vacuum disc clamping.


Videos

FA23 offline automatic printer

Camera-controlled, automatically aligned offline stencil printer.
