BLC-3 label marking

Equipment designed for high precision label application, where the label is applied to the product or part. The head is moved by an X-Y motion system between the printer and the product. Magnetically lockable supports aid quality application.

  • Robust construction
  • Built-in 600 dpi printer
  • Min. label size 5 x 5 mm
  • Cycle time 2.5 sec/label
  • Label rotation in 1 degree steps
  • Vacuum label sensor
  • CCD camera reading before label capture
  • Quick changeover
  • Optional by-pass operation
  • UPS
  • Lighting tower
  • Magnetic support
  • Lateral panel attachment
  • Can be marked as panel:
    • Size: 80 x 508 mm
    • Thickness: 60 x 460 mm
  • Machine dimensions: 850 x 1680 x 1440 mm (W × D × W)
  • Weight: 700 kg
  • Double-sided labelling (with integrated panel turner)
  • Program-controlled width adjustment
  • PCB position and orientation check
  • Database and network connection
  • A second printer for different size of label
  • Labeling head


BLC-3 labelling machine

From the label printer, the applicator head accurately applies the label to either a panel or a component. The PCB is held from below by a manually adjustable magnetic support.
