A310 Preparation unit (obsolate)

This Scheugenpflug material preparation unit simultaneously prepares, maintains the correct quality and transports the material to the feed head. It is the ideal solution for airtight or heated storage of moisture-sensitive materials (polyurethanes), for de-bubbling or for homogenisation of filled materials that are prone to separation. The unit is equipped with double pistons to ensure a continuous flow of material to the dispensing head. The A310 TP (Top Pump) sub-type is the ideal choice for the preparation of small quantities, e.g. for costly materials from 1 to 5 litres. For highly viscous materials, the A310 TT (Top Tank) is the solution.

GO TO THE MANUFACTURER'S WEBSITE

DOWNLOAD DATA SHEET

  • Details
  • Parameters
  • Options
  • For 1 or 2 components between 1 and 60 litres
  • Vacuum preparation adjustable up to 5 mbar to ensure a perfectly bubble-free, moisture-free, homogeneous material
  • Redundant pump design for continuous material transfer
  • Built-in mixing against separation of charged materials
  • Scheduled material circulation between the feed head and the preparation unit
  • Tank, pump and tube heating
  • Inspection window with lighting at the top of the tank
  • Automatic suction unit for refilling from 200 litre drums
  • A310 for self-leveling materials and A310 TP for higher viscosity materials

Dimensions:

  • W × D × H: 700 × 1950 × 1165 mm (1K-60 l)
  • W × D × H: 700 × 1950 × 1585 mm (2K 60/60l)

Weight:

  • approx. 350 kg (1K 60 l)
  • approx. 400 kg (2K 60/60 l)

Capacity: 290 ml/stroke

Power supply: 3 x 400 V~, 50/60 Hz, CEE 16 A

Ejector: up to 150 mbar (6 bar mains air pressure)

Vacuum pump: up to 5 mbar

Heating: max 80°C

Mixing speed: 39 rpm

A310 TP (Top Pump)

  • preparation of small quantities of costly materials 1-5 litres
  • preparation of slightly self-spreading materials with higher viscosity

A310 TP TT (Top Pump + Top Tank)

  • for high viscosity and low-volume materials

  • A310 Top Pump

    Preparation unit for small quantities or costly materials

  • A310 Top Tank

    Preparation unit for high viscosity materials

Videos

Scheugenpflug A310

Popular preparation trolley for moisture and airtight preparation and application of self-leveling materials.

Scheugenpflug A310TP

TopPump design for smaller volumes or higher viscosity materials.
