A220 and A280 material dispensers

Solution for bucket materials

These machines are ideal solutions for high viscosity bucket packaging of materials with up to 1 or 2 components. Thanks to this unique Scheugenpflug pressure plate design, bucket change and deaeration is automatic in less than 5 minutes. For non-abrasive materials the A220 is the ideal choice while for highly abrasive filled materials the A280 is the ideal choice.

GO TO THE MANUFACTURER'S WEBSITE

DOWNLOAD DATA SHEET

  • Details
  • Parameters
  • Handling 20 litre buckets (Hobbock)
  • For high viscosity, non-abrasive materials A220
  • For high viscosity, abrasive, filled materials A280
  • 1 or 2 component design
  • Airlock-free, automated, rapid (<5 minutes) bucket exchange with minimal material loss. With patented Scheugenpflug developed pressure plates
  • With SCP210 controller, even for dispensing head control
  • Material barcode reading
  • External authorisation and monitoring of barge exchange
  • External control
  • Redundant dispensing

Dimensions:

  • W × D × H: 900 × 1850 × 700 mm (1K-60 l)
  • W × D × H: 1500 × 1850 × 700 mm (2K-60/60l)

Weight:

  • approx. 230-300 kg (1K)
  • approx. 400-470 kg (2K )

Standard bucket size (custom design optional):

  • internal diameter: 282 mm
  • outer diameter: 305 mm

Capacity:

  • A220 submersible pump 30 cm3/stroke
  • A280 double piston pump 290 cm3/piston/stroke

Power supply: 3 x 400 V~, 50/60 Hz, CEE 16 A

  • A280 1C

    Material dispensing system also for 1-component materials.

  • A220 1C (redundant)

    Continuous material supply even during barrel change

  • Printed from

    Patented double wall, vacuum printing plate

Videos

Scouring plough A280

Stable material transfer, with automatic deaeration bucket change for highly abrasive, filled materials.

Scheugenpflug A220

Robust submersible pump dispenser for non-abrasive, high viscosity materials.
