Yamaha YRM20 – P & F
Premium high speed pick and place machine
Introduction
For both high mix and high volume production, the Yamaha YRM20 is your go-to solution. With a renewed and enhanced user interface, streamlined production preparation, and seamless transition support, the YRM20 is designed to deliver premium quality while maximizing productivity.
For production lines demanding high speed, we recommend the RM Rotary Head, a cutting-edge innovation combining YSM and Σ technologies. This head enables the YRM20 to reach an impressive speed of up to 115,000 CPH with high-speed feeder support, transferring common parts with 98% efficiency and a remarkable 25μm accuracy.
When versatility is key, the improved universal HM Head is your best choice. It handles everything from the smallest components to odd-shaped parts with precision and speed, achieving up to 98,000 CPH with consistent accuracy.
Key Features of the YRM20 Platform:
- Windows 10-based platform
- Enhanced servo system
- Increased PCB size and transport speed
- Intuitive, clean user interface
- Advanced new part detection
- Nozzle level management
Like all Yamaha machines, the YRM20 is part of the One Stop Smart Solution, offering a complete Yamaha production line integration for a fully optimized workflow.
Details
- 2 beam 2 head design
- Insert parts: from 0201 mm 55 x L 100 mm (H15 mm)
- Increased planting quality by using a “Low-impact nozzle”.
- Modern user interface
- High speed feeder to serve RM head speed
- Improved DUAL Stage Conveyor System
- Insertion accuracy ±0.025mm Cpk≧1.0
- Improved teachable intelligent component recognition system
- Side camera
- Pipette cleaning station
- Touch screen display
- 128 interchangeable feeders 8 mm feeder space
Parameters
- Size of panel that can be inserted:
- L 50 x W 50 to L 810 x W 510 mm
- Insertion speed (IPC9850):
- 2x RM head: 115.000/78.500 CPH
- 2x Inline FM head: 98.000/68.000 CPH
- Dimensions: 1374(width) x 1948(depth) x 1445(height) mm
- Weight: 2250 kg
- Power supply: 3~ 400 V, 50/60 Hz, CEE 16 A
Image gallery
Product showcase videos
YRM20 - simplicity, versatility
In the video you can see a general description of the YRM20 implanter in action.
