PBT CompaClean
Cleaning machine for soldering frames or PCBs
Introduction
The PBT Compaclean II cleaning equipment, in different configurations, is the ideal solution for both the washing of implanted products and the washing of solder frames with higher capacities. Thanks to the innovative water treatment, detergent consumption is minimised. The wash baskets move over 68 high-pressure nozzles on the top and bottom, ensuring that the products do not overshadow each other, i.e. the detergent reaches all points of the products.
Details
- High pressure washing spray in air technology
- Patented wash basket moving over the nozzles, even wash with minimal shadow effect
- Heated cleaning fluid max. 60°C
- Heated rinsing liquid max. 45°C
- Drying temperature max. 120°C
- Washing capacity 140 eurocards (100 x 160 mm) or 6-8 solder frames (450 x 500 x 500 mm)
- Industrial PC control, washing program writing
- 3 levels of solvent filtration
- 4 levels of integrated ion exchange water treatment
- Controlled parameters
- Cleaning time
- Cleaning temperature
- Warm air drying time
- Flushing water quality (conductivity)
Product Options
- Multiple configurations (washer-rinse and washer-pre-rinse-rinse)
- Central swivel arm positioning for double deck wash baskets
- Connectivity to an external water source
- Zero Drain, no run-off operability in the production area
- Detergent concentration measurement – Zestron eye / Kyzen Analyst
- Signal tower
- Product and solder frame barcode scanning, traceability
Parameters
- Cycle times:
- Mounted panel 40-60 minutes
- Soldering frame 30-40 min
- Workspace dimensions: 450 x 500 x 500 mm (W x H x D)
- Equipment dimensions: 880 × 1680 × 1866 mm (W x H x D), 380 kg
Image gallery
Product showcase videos
CompaClean
Machine for PCB and palette cleaning with easy handling and programmability.
