PBT MiniSwash
A budget stencil cleaning machine
Introduction
The PBT MiniSwash II is suitable for the cleaning of solderpaste or adhesive frommetal stencils and frames, while MiniSwash III is able to clean small quantities of PCBs used in SMT production. The performance/price ratio of the this cleaning machine is outstanding on the market. Thanks to its special design, it can safely clean both PumpPrint and stencils thinner than 100 microns.
Details
- MiniSwash II cleaning of stencils, squegees and misprints
- Alu frames, VectorGuard both cleanable
- MiniSwash III cleaning of PCBs too
- Works with water-based detergents
- Stainless steel chamber and casing
- High pressure cleaning, spray in air technology
- Double-sided balanced spray pressure with synchronized rotary arms
- Hot air drying process with programmable temperature and extraction
- Extremely low detergent consumption
- Controlled parameters:
- Cleaning time
- Warm air drying time
- Monitoring the cleaning fluid level
- Monitoring the quality of flushing fluid
- Monitoring mechanical filter status
Product Options
- Multiple configurations (cleaning, cleaning-rinse and cleaning-rinse-final rinse)
- Connectivity to an external water source
- Zero Drain, drainless operability in the production area
- Connectable to central extraction
- Lighting tower
- Stencil and product barcode scanning
Parameters
Typical cycle times:
- Stencil 10-15 minutes
- Mounted panel 30 minutes
Max. washable size: 740 x 740 x 80 mm
Equipment dimensions: 1 503 x 777 x 1 191 mm (W x H x D), 250 kg
Image gallery
Product showcase videos
MiniSwash II budget friendly stencil, squegee, misprint cleaning
MiniSWASH machines are spray-in-air (SiA) cleaning systems designed as single chamber technology with synchronised spray arms. Budget friendly solution for small to medium volume cleaning.
MiniSwash stencil washer, the compact solution
The MiniSwash machine has a built-in high pressure spray wash, up to distilled water rinse and heated air knife for perfectly clean and dry stencils.
