Nutek LMC-S3
Inline or stand alone engraving machine
Introduction
NUTEK also has extensive experience in laser marking and laser label engraving. In addition to traditional CO2 laser solutions, they have developed special technologies such as the label implantation and laser engraving combo unit. The Nutek LMC-S3 Laser marking system enables the same equipment to apply labels in places where laser application would not otherwise be possible. Their laser engraver functions equally well as a production line and as a separate station. Operating concepts include a moving laser head and laser beam positioning with only mirrors. Depending on application, panel size, speed requirements, we can offer the best solution.
Details
- CCD camera inspection
- Large marking area
- Industrial PC control
- Text, barcode, 2D code and graphics markup
- Side scoop
- Quick changeover
- UPS
- Lighting tower
- By-pass operation
Product Options
- Double-sided marking with integrated inverter
- PCB position and orientation check
- Program-controlled tape width adjustment
- Position point detection and positioning
- Bad-mark detection with integrated code reader
- External extraction
- Database and network connection
- Fiducial recognition option
- PCB orientation
Parameters
- Panel size: 508 x 460 mm
- Thickness: 0,6 – 3 mm
- Machine dimensions: 850 x 1558 x 1752 mm (W × D × W)
- Weight: 700 kg
Image gallery
Product showcase videos
Nutek LMC Laser Marker
Robust laser engraving machine for the SMT industry.
Marking quickly and accurately
The equipment can be used as an inline production line or as a stand alone marking island.
